20XD with 225 Pro XS with 1.75 gears and low water lower and 12" plate. What props are most running tournament loaded ? Blade styles and pitch? Thanks Jeff S.
20XD with 225 Pro XS with 1.75 gears and low water lower and 12" plate. What props are most running tournament loaded ? Blade styles and pitch? Thanks Jeff S.
I have never propped a boat with your set-up but it seems like the Bravo fits just about any application for a fishing.
I would also say that a TXP 4 O/T would be a great fishing load prop. I have had very good results with those two props for a fishing load and thats all I run for tournaments. I have not found an over the hub to satisfy my needs for fishing as of yet but I have not tried many. I am stuck on the Bravo.
Pitch I really have no idea. but I am sure someone can fill you in. Maybe 26"
Actually now that I think about it I would be VERY interested to see how the new Fury would run. I have heard very good things about that prop. The Fury may be the way to go.
I know of a guy running the same rig with a 28 Pro ET, it's a running son of a gun! Not sure of his gearset though.
[I]20XD Bullet-Mercury Promax[I]
I had the same set-up on my last boat and the best runnin prop I found was the
26 Trophy which has a reputation for slingin blades,but fortunately I ran the same prop for years without any problems.It was good on hole shot,awesome mid and top.
2016 Allison XB21 XST
2021 Mercury 250R
He makes it sound like a coned torque master is the way I take it.
28-30 Bravo 1 for fishing
28-29 Hydromotive for speed
<TABLE WIDTH="90%" CELLSPACING=0 CELLPADDING=0 ALIGN=CENTER><TR><TD>Quote, originally posted by Yellow Jacket »</TD></TR><TR><TD CLASS="quote">28-30 Bravo 1 for fishing
28-29 Hydromotive for speed</TD></TR></TABLE>
Dang I didn't think he would be able to turn a prop that steep.
Lower is a bob's coned torque master. Rich (yellowjacket), can these 225's turn a 30" bravo1 ? I figured a 28 but a 30 is pretty tall. What kind of speeds are these running. How heavy are you loaded with these props? Any setup help could be very helpfull. Thanks Jeff S.
Fishing Load:
Two guys
9-Rods in Rod Box on left.
6-Rods in tubes in top front center storage, 8-Rods in sleeves, landing net and push pole in front center storage.
6-Plano boxes in storage in front of drivers console, spinner bait box and plastics in canvas bag, CD/Radio and four speakers.
82lb. 24V. Motor Guide hand control.
1-spare prop, anchor, fire extinguisher and some tackle behind passenger seat storage compartment.
2-life jackets, throw cushion and dry storage bag behind driver.
1-3 bank battery charger, three batteries and oil tank in rear compartment.
at least half a tank of fuel and full cooler under center seat.
Has 14" Rapid Jack, LU has three upper holes plugged on each side.
30 Bravo 1 5,800 RPM @ 81mph.
28 Hydromotive 6,000 @ 83mph.
Let me know if I can help you
Heck thats pretty dang good there Rich. And the slip numbers don't seem to be too bad.
FSHRMN1010. I think with the nosed cone you will be able to run higher and maybe pick up a mph or 2. Sounds like Rich (yellowJacket) is your man to talk to for this set-up
Very interesting. Learn somthing new every day.
Yeah, I agree I'm giving up a few mph with the Torque Master LU. A Cone or Sport Master should / may gain a few more mph
try a 28 txp 4 blade, should run you close to 89 mph with a load
and a 28 hydromotive should put you around 87-88 mph..
motor height around 1/2 in above the pad
